The vertical pressure tester (top pressure tester) is suitable for testing the vertical pressure strength, top pressure strength, and bottle pressure resistance of various beverage bottles, carbonated beverage bottles, PET bottles, purified water bottles, mineral water bottles, oil bottles, cola bottles, plastic bottles, and cans. Widely applied in industries such as food, medicine, and daily necessities. It is also suitable for suppliers of well-known brands such as Yibao, Yili, Jingtian, Watsons, Wahaha, Nongfu Spring, etc. It is a mandatory testing instrument for various quality inspection agencies, beverage factories, and packaging material production enterprises.

Vertical load pressure refers to the ability of beverage bottles to withstand the pressure of the upper layer of goods during stacking. Therefore, the top pressure tester is also known as a vertical load pressure tester or a plastic bottle top pressure tester. Simply defined as a pressure testing machine, it can also be classified as a universal testing machine. The top pressure tester is a special name given in the testing industry of special products, which has been listed as a national standard. Generally, in the packaging industry, food testing, PET bottle testing, and some container compression testing, this type of testing machine is called a top pressure tester

The reason for the unqualified vertical pressure index is that the enterprise cut corners and reduced the amount of resin used, resulting in the low weight of the bottle preform in the beverage bottle. Some standards have clear provisions for this indicator. For example, QB/T 1868-2004 "Polyethylene terephthalate (PET) carbonated beverage bottles" stipulates that the vertical pressure index should be ≥ 200N.

Technical characteristics of HP-ZYY01 vertical load pressure tester (top pressure tester)

★ Micro computer control, menu interface, PVC operation panel, and large LCD screen display

★ Intelligent configurations such as limit protection, overload protection, automatic return, and power-off memory ensure user operation safety

★ It has multiple functions such as parameter setting, printing, viewing, clearing, calibration, etc

HP-ZYY01 Vertical Load Pressure Tester (Top Pressure Tester) Testing Principle

The sample is placed between the two clamps of the fixture, and the two clamps move relative to each other. Through the force sensor located on the moving clamp and the displacement sensor built-in in the machine, the force and displacement changes during the test process are collected, and the compressive strength performance index of the sample is calculated.

The HP-ZYY01 vertical load pressure tester (top pressure tester) meets the standard

GB/T 17200, QB/T 1868, GB/T10440, QB 2357, QB/T 2665, BB/T 0044

Technical specifications of HP-ZYY01 vertical load pressure tester (top pressure tester):

1. Maximum test force: 500N 1000N 2000N 5000N (optional)

2. Range: 2% -100% of maximum force;

3. Test force accuracy; Better than ± 1%

4. Displacement resolution: 0.01mm;

5. Displacement measurement accuracy: better than ± 1%;

6. Travel: 600mm or 1000mm (optional)

7. Displacement speed control range: 1mm/min~500mm/min

8. Displacement speed control accuracy: better than ± 1%

9. Testing machine level: Level 1

10. Deformation indication error: ≤ ± (50+0.15L)

11. Test machine size: 500 * 500 * 850mm

12. Power supply: 220V, 50Hz

13. Weight: 100KG

14. Sample diameter ≤ 220 mm

15. Sample height ≤ 600mm

Instrument configuration

Host, pressure resistant fixture, professional software.
