Product Name: HP-ZRD-1000C Flexibility Tester

Application industries: Paper, wet wipes, insulation materials, mica tape, polyester film, plastic film, composite materials, release paper, metal foil, diaphragm, backboard materials and other products

Testing item: Flexibility test

Complies with the relevant provisions of GB/T8942 "Method for determining the softness of paper".

1、 Functional features:

1. Speed regulation system: using motors and reducers, with stable and reliable performance, equipped with protective devices such as overcurrent, overvoltage, and overload. The speed regulation range can reach 1-1000 mm/min.

2. Transmission mechanism: The transmission part adopts a circular arc synchronous toothed belt and a precision screw pair transmission, which ensures smooth transmission, low noise, and high transmission efficiency.

3. Operating system: Touch key operation mode, real-time display on LCD display, all Chinese operation, overcoming the problem of old style digital tube display prone to malfunctions, and it is beautiful, elegant, convenient and fast.

4. Automatic display: Throughout the entire test process, the LCD displays real-time test force, displacement, peak value, operating status, operating speed, etc.

5. Automatic control: After inputting the experimental parameters, the experimental process can be automatically completed.

6. Sample judgment: After the sample is completed, the moving crossbeam will automatically stop moving.

7. Special attachments: equipped with softness testing attachments

8. Display function: At the end of the experiment, the maximum force during the experiment can be automatically displayed and memorized;.

2、 Technical indicators:

1. Model: Single arm (touch screen display)

2. Measurement range: 10-5000mN (50 N)

3. Test speed: (1.2 ± 0.24) mm/s

4. Test head stroke: (12 ± 0.5) mm (adjustable)

5. Accuracy level: Level 1

6. Slit width: 5mm; 6.35mm; 10mm; 20mm (width error should not exceed ± 0.05mm)

7. Experimental power: minimum resolution 0 001N

8. Displacement measurement: resolution of 0.01mm

9. Test head pressing depth: 8mm+0.5mm

10. Stepless speed regulation: using digital DC motors and control systems

11. Experimental space adjustment mechanism: digital motor, synchronous belt drive

12. Host size: 540 * 280 * 1450mm

13. Appearance: In accordance with the national GB/T8942 standard

14. Power supply: 200V 50Hz

15. Weight: approximately 70Kg

3、 Basic system configuration:

1. 1 main unit (single arm)

2. 1 motor

3. 1 set of deceleration system

4. 1 load sensor

5. 1 set of precision screw pairs

6. 1 set of limit switches

7. 1 touch operation display

8. 1 set of softness testing aids

9. 1 set of power connection cables

10. Technical information: including: user manual, certificate of conformity, packing list

4、 Quality assurance:

Warranty Period: The warranty period is one year. During the warranty period, any malfunctions caused by product quality issues will be covered by free warranty and replacement of faulty parts for free;

Outside the warranty period: providing long-term technical support: If the instrument malfunctions outside the warranty period, the seller is exempt from maintenance fees and only charges basic material fees. Any damage to the instrument during transportation shall be borne by the seller
