The soft capsule elasticity (hardness) tester is suitable for measuring the hardness, elasticity, etc. of different soft capsules, providing reference data for selecting product formulas and processes. Soft capsule elasticity tester, also known as soft capsule hardness tester, soft capsule elasticity tester, etc.
Soft capsules, also known as capsules, are capsule preparations made by sealing liquid or liquid solid drugs in soft capsule materials after treatment; During the processing of soft capsules, as the concentration of gelatin gradually increases, the softness and hardness of gelatin will increase very quickly. The increase in softness and hardness of gelatin is much greater than the rate of increase in gelatin concentration. Testing the hardness of soft capsules has guiding significance for selecting product formulas and processes.
Testing principle of soft capsule elasticity (hardness) tester:
The soft capsule tester measures the hardness and resilience of soft capsules under different states by conducting a downward pressure test on them; Puncture testing of soft capsules can obtain the force required for capsule penetration and the deformation during capsule rupture, thereby confirming their hardness and toughness.
Characteristics of Soft Capsule Elasticity (Hardness) Tester:
1. The touch screen display displays real-time force values, displacement deformation, fully automatic testing, and automatically saves the maximum value of the current test; The display interface can display the test curve in real time; Test real-time parameters such as speed and deformation.
2. Using a high-precision, fully digital speed control system and precision reducer, the precision screw pair is driven for testing, achieving a wide range of adjustment of the test speed and smooth operation.
3. Adopting high-precision sensors and professional measurement and control software, with high testing accuracy, wide testing range, and simple operation.
4. Equipped with a standard micro printer, it can print results at any time and can calculate multiple test results, maximum, minimum, and average values.
5. After selecting a computer, the software curve and test results are displayed on the same interface, including the curve and test data. Test data such as force, time, distance, and software displayed synchronously during the testing process. Data analysis, result data and curves, can store data infinitely, and can print A4 reports.
Technical parameters of the soft capsule elasticity (hardness) tester:
Measurement range: 50 N (optional for 100 N, 500 N, or 1000 N)
Resolution: 0.1N
Accuracy: ± 0.5%
Test speed: (1-300) mm/min
Upper pressure head: 10mm pressure head
Parallel upper and lower pressure plates:<0.025mm
Lower pressure plate diameter: 120 mm
External dimensions: 430 x 350 x 710mm
Mass: 45kg
Power supply: 220V, 50Hz
Configuration of Soft Capsule Elasticity (Hardness) Tester
Standard configuration: Soft capsule elasticity (hardness) tester host, testing aids, micro printer. (Single machine can also be used)
Purchase: Lenovo computers, inkjet printers, online computer control software.
